Tín Bảo Lan (TBL)
  • - Recommended: for 501-750 User Network
  •  -Internal Storage: 2x 240 GB SSD
  •  -Threat Protection Throughput: 7 Gbps
  •  -Site-to-Site VPN Tunnels: 2,000
  • - Concurrent Sessions: 8,000,000
  •  -1 Year Services: 24x7 FortiCare Contract & FortiGuard Unified Threat Protection (UTP)

Giá Liên Hệ






  • Thông tin chi tiết
  • Đánh giá
Mã sản phẩm  FG-601E-BDL-950-12
Interfaces and Modules
10 GE SFP+ Slots  2
GE RJ45 Interfaces  8
GE SFP Slots  8
GE RJ45 Management Ports  2
USB Ports  2
RJ45 Console Port  1
Local Storage  2x 240 GB SSD
Included Transceivers  2x SFP (SX 1 GE)
System Performance — Enterprise Traffic Mix
IPS Throughput 2 10 Gbps
NGFW Throughput 2, 4 9.5 Gbps
Threat Protection Throughput 2, 5 7 Gbps
System Performance and Capacity
IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) 36 / 36 / 27 Gbps
IPv6 Firewall Throughput (1518 / 512 / 64 byte, UDP) 36 / 36 / 27 Gbps
Firewall Latency (64 byte, UDP)  2 μs
Firewall Throughput (Packet per Second) 40.5 Mpps
Concurrent Sessions (TCP)  8 Million
New Sessions/Second (TCP)  450,000
Firewall Policies  10,000
IPsec VPN Throughput (512 byte) 1 20 Gbps
Gateway-to-Gateway IPsec VPN Tunnels  2,000
Client-to-Gateway IPsec VPN Tunnels  50,000
SSL-VPN Throughput  7 Gbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) 10,000
SSL Inspection Throughput (IPS, HTTP) 3 8 Gbps
SSL Inspection CPS (IPS, avg. HTTPS) 3 5,500
SSL Inspection Concurrent Session (IPS, avg. HTTPS)3 800,000
Application Control Throughput (HTTP 64K) 2 15 Gbps
CAPWAP Throughput (1444 byte, UDP)  18 Gbps
Virtual Domains (Default / Maximum)  10 / 10
Maximum Number of Switches Supported  64
Maximum Number of FortiAPs (Total / Tunnel) 1,024 / 512
Maximum Number of FortiTokens 5,000
Maximum Number of Registered Endpoints  2,000
High Availability Configurations  Active-Active, Active-Passive, Clustering
Dimensions and Power
Height x Width x Length (inches)  1.75 x 17.0 x 15.0
Height x Width x Length (mm) 44.45 x 432 x 380
Weight  16.6 lbs (7.5 kg)
Form Factor  1 RU
Power Consumption (Average / Maximum)  129 W / 244 W
Power Source  100–240V 60–50Hz
Current (Maximum)  6A @ 100V
Heat Dissipation 613 BTU/h
Redundant Power Supplies (Hot Swappable)  optional
Operating Environment and Certifications
Operating Temperature  32–104°F (0–40°C)
Storage Temperature  -31–158°F (-35–70°C)
Humidity  10–90% non-condensing
Noise Level  59 dBA
Operating Altitude  Up to 7,400 ft (2,250 m)
Compliance  FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB
Certifications  ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6

Tùy chọn Module quang SFP cho Firewall FortiGate 601E

1 GE SFP LX transceiver module FN-TRAN-LX 1 GE SFP LX transceiver module for all systems with SFP and SFP/SFP+ slots.
1 GE SFP RJ45 transceiver module FN-TRAN-GC 1 GE SFP RJ45 transceiver module for all systems with SFP and SFP/SFP+slots.
1 GE SFP SX transceiver module FN-TRAN-SX 1 GE SFP SX transceiver module for all systems with SFP and SFP/SFP+ slots.
10 GE SFP+ Transceiver Module, Short Range FN-TRAN-SFP+SR 10 GE SFP+ transceiver module, short range for all systems with SFP+ and SFP/SFP+ slots
10 GE SFP+ Transceiver Module, Long Range FN-TRAN-SFP+LR 10 GE SFP+ transceiver module, long range for all systems with SFP+ and SFP/SFP+ slots
10 GE Copper SFP+ Transceiver Module, up to 30m FN-TRAN-SFP+GC
10 GE copper SFP+ RJ45 transceiver. For FortiSwitch only, up to 30m.
10 GE SFP+ Active Direct Attach Cable, 10m / 32.8 ft SP-CABLE-ADASFP+ 10 GE SFP+ active direct attach cable, 10m / 32.8 ft for all systems with SFP+ and SFP/SFP+ slots

Tùy chọn Power nguồn cho Firewall FortiGate 601E

Optional Power Supply SP-FG300E-PS AC power supply for FG-300/301E, FG-400/401E, FG-500/501E, FG-600/601E, FAZ-200F/300F/800F and FMG-200F/300F.
