| Mã sản phẩm |
FG-81E-BDL-950-12 |
| Hardware Specifications |
|
| GE RJ45/SFP Shared Media Pairs |
2 |
| GE RJ45 Ports |
12 |
| GE RJ45 PoE/+ Ports |
- |
| GE RJ45 DMZ/HA Ports |
2 |
| USB Ports |
1 |
| Console (RJ45) |
1 |
| Internal Storage |
128GB |
| System Performance |
|
| Firewall Throughput (1518 / 512 / 64 byte UDP packets) |
4 / 4 / 4 Gbps |
| Firewall Latency (64 byte UDP packets) |
3 μs |
| Firewall Throughput (Packets Per Second) |
6Mpps |
| Concurrent Sessions (TCP) |
1.3 Milion |
| New Sessions/Second (TCP) |
30,000 |
| Firewall Policies |
5,000 |
| IPsec VPN Throughput (512 byte) 1 |
2.5 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels |
200 |
| Client-to-Gateway IPsec VPN Tunnels |
2,500 |
| SSL-VPN Throughput |
200 Mbps |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) |
200 |
| SSL Inspection Throughput (IPS, HTTP) 3 |
180 Mbps |
| Application Control Throughput (HTTP 64K) 2 |
900 Mbps |
| CAPWAP Throughput (HTTP 64K) |
920 Mbps |
| Virtual Domains (Default / Maximum) |
10 / 10 |
| Maximum Number of Switches Supported |
8 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) |
32 / 16 |
| Maximum Number of FortiTokens |
100 |
| Maximum Number of Registered FortiClients |
200 |
| High Availability Configurations |
Active / Active, Active / Passive, Clustering |
| System Performance — Optimal Traffic Mix |
|
| IPS Throughput 2 |
1.5 Gbps |
| System Performance — Enterprise Traffic Mix |
|
| IPS Throughput 2 |
450 Mbps |
| NGFW Throughput 2, 4 |
360 Mbps |
| Threat Protection Throughput 2, 5 |
250 Mbps |
| Dimensions |
|
| Height x Width x Length (inches) |
1.65 x 8.5 x 7 |
| Height x Width x Length (mm) |
42 x 216 x 178 |
| Weight |
2.65 lbs (1.2 kg) |
| Form Factor |
Desktop |
| Environment |
|
| Power Required |
100–240V AC, 50–60 Hz |
| Maximum Current |
100V AC / 0.7A, 240V AC / 0.3A |
| Total Available PoE Power Budget* |
N/AWould |
| Power Consumption (Average / Maximum) |
20 W / 72 W |
| Heat Dissipation |
245.67 BTH/h |
| Operating Temperature |
32–104°F (0–40°C) |
| Storage Temperature |
-31–158°F (-35–70°C) |
| Humidity |
10–90% non-condensing |
| Noise Level |
Fanless 0 dBA |
| Operating Altitude |
Up to 16,404 ft (5,000 m) |
| Compliance |
FCC Part 15B, Class B, CE, RCM, VCCI, UL/cUL, CB, BSMI |
| Certifications |
ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN |
